Specification

Authentication Method Biometric
Dust/ Water Resistance X
Memory Max Users 200,000
Fingerprints
(Templates)
FP : 400,000 (1:1)
100,000 (1:N)
Iris : 400,000 (1:1)
40,000 (1:N)
Logs 10,000,000
Images 20,000
Communication With Server TCP/IP
Other USB
Wireless LAN(Wi-Fi) Optional
Wiegand OUT O
RS232 O
RS485 O
Wiegand IN O
Display LCD 5″Color Touch
Backlight O
Embedded Camera Dual
Card 125khz-EM O
HID Prox O
HID iclass O
13.56MHz Smart Card O
Keypad Touch Screen
Function keys SOFT
Door Phone Volp
FP Sensor Platen Area 16.6 X 21.6 mm
Resolution 500 dpi
Authentication
Speed
(1:1) < 0.2 sec
1:N(1,000) < 0.7 sec
Dimension (W) X (H) X (D) mm 160.6 X 214 X45.4
FRR /FAR 0.1% / 0.0001%
Operating Temperature -20 ~ 60℃
