Specification

Fingerprint Type Optical
Resolution 500dpi
Gray Scale 256gray
Platen Size (W x L) 16.6 x 21.6 mm
Sensing Area (W x L) 16 x 21 mm
Auto Sensing O
Speed 10 frames Per second(fps)
Interface USB 2.0 (High Speed)
Operating Temperature -20 ~ 60℃
Operating Humidity 10 ~ 90%, non-condensing
Dimension (W x H x D) 75 x 39.4 x 17.2 mm
Certifications KC, CE, FCC, ROHS, FBI PIV+FAP20
Image Format ISO 19794-4, WSQ, RAW, BMP
Templates Type VIRDI, ISO 19794-2, ANSI 378
LFD O
Operating System Android
Card Type X
Opertating Software (Server solution)
