Specification
| Fingerprint Type | Optical |
| Resolution | 500dpi |
| Gray Scale | 256gray |
| Platen Size (W x L) | 16.6 x 21.6 mm |
| Sensing Area (W x L) | 16 x 21 mm |
| Auto Sensing | O |
| Speed | 10 frames Per second(fps) |
| Interface | USB 2.0 (High Speed) |
| Operating Temperature | -20 ~ 60℃ |
| Operating Humidity | 10 ~ 90%, non-condensing |
| Dimension (W x H x D) | 75 x 39.4 x 17.2 mm |
| Certifications | KC, CE, FCC, ROHS, FBI PIV+FAP20 |
| Image Format | ISO 19794-4, WSQ, RAW, BMP |
| Templates Type | VIRDI, ISO 19794-2, ANSI 378 |
| LFD | O |
| Operating System | Android |
| Card Type | X |
| Opertating Software (Server solution) | – |
