Specification

Authentication Method Biometric
Dust/ Water Resistance IP65
Memory Max Users card (1:1)/(1:N) 500,000
Fingerprint
(Base on one finger
enrollment per user)
1:1 X
1:N X
Face
(Base on five Face
enrollment per user)
1:1 20,000
1:N 20,000
Iris
(Base on 2 eyes (L/R)
enrollment per user)
1:1 X
1:N X
Templates Fingerprint 1:1 X
1:N X
MAX Templates per Finger X
MAX Finger per User X
Face 1:1 20,000
1:N 20,000
MAX Templates per Finger X
Iris 1:1 X
1:N X
MAX Templates per Eyes X
MAX Templates per User X
Logs 10,000,000
Images 20,000
Communication with server TCP/IP
other USB
Wireless LAN(Wi-Fi) O
Wiegand OUT O
RS232 O
RS485 O
Wiegand IN O
Display LCD 5”Color Touch
Backlight 0
Embedded Camera Dual
Card 125khz-EM O
HID Prox O
HID iclass O
13.56MHz Smart Card O
Keypad Touch Screen
Function keys SOFT
Door Phone X
FP Sensor (Platen Area) X
Resolution X
Dimension (W) X (H) X (D) mm 94 x 224 x 35.5mm
FRR /FAR 0.1% / 0.0001%
Operating Temperature -20 ~ 60℃
Opertating Software (Server solution) UBio Alpeta
