NScan-SDL

All-in-one the Slimmest Optical
Finger Scanner OEM Module

NScan-SDL은 올인원 센서 및 최고 지문 인증 알고리즘이 내장 된 독립형 지문 모듈입니다.

Patented Live & Fake Finger Detection

Interface UART(TTL)

13.4mm Optical Sensor

Auto-SensingFeature

Specification

Fingerprint Type OPTICAL
Resolution 500dpi
Gray Scale 256 gray
Template Capacity 1,000 Template
Log Capacity X
Enrollment Time < 1 sec
Verification Time < 1 sec
Host Communication UART(TTL)
Power Comsuption (mA) Standby: Max 110mA
Operation: Max 130mA
Supply Voltage DC 3.3V ± 0.2V
Encryption Seed 128
Operating Temperature -20 ~ 60°C
Operating Humidity 10 ~ 90ºC non-condensing
Dimension (W x H x D) 53.6 x 32.6 x 13.4 mm
FRR (False Rejection Rate) < 0. 1%
FAR (False Acceptance Rate) < 0. 0001%
LFD O
