Specification

CPU 32bits RISC processor (ARM Cortex-M3 Core) LAN 10/100M Ethemet (Auto detecting)
Memory 8MB serial flash Backup Battery DC12V 7A (Option)
Power Adapter DC15V 6A Display Status LED
Operation Environment -20 ~ 60℃ / Lower than 90% RH Lock Interface 4 Locks
Zone Interface 8 Zone (Each port dual use) Bell Interface Monitored bell / siren port (1 port)
Schedules 1,024 Event Logs 51,200
Max Users 50,000 Communication Port RS485 Reader port / Wiegand input ports
Programmable inputs / Programmable outputs
