| Fingerprint Type | OPTICAL |
| Resolution | 500dpi |
| Gray Scale | 256 gray |
| Template Capacity | 16,000 Template |
| Log Capacity | 12,280 |
| Enrollment Time | < 0.7 sec |
| Verification Time | < 0.7 sec |
| Host Communication | RS-232 |
| Power Comsuption (mA) | Standby: Max 120mA Operation: Max 200mA |
| Supply Voltage | DC 5V ±0.2V |
| Encryption | Seed 128 |
| Operating Temperature | -20 ~ 60°C |
| Operating Humidity | 10 ~ 90%, non-condensing |
| Dimension (W x H x D) | 43 x 60 x 8 mm |
| FRR (False Rejection Rate) | < 0. 1% |
| FAR (False Acceptance Rate) | < 0. 0001% |
| LFD | O |
