Specification
Fingerprint Type | OPTICAL |
Resolution | 500dpi |
Gray Scale | 256 gray |
Template Capacity | 1,000 Template |
Log Capacity | X |
Enrollment Time | < 1 sec |
Verification Time | < 1 sec |
Host Communication | UART(TTL) |
Power Comsuption (mA) | Standby: Max 100mA Operation: Max 120mA |
Supply Voltage | DC 5V ± 0.2V (S5) DC 3.3V ± 0.2V (S3) |
Encryption | Seed 128 |
Operating Temperature | -20 ~ 60°C |
Operating Humidity | 10 ~ 90%, non-condensing |
Dimension (W x H x D) | 21 x 53 x 27 mm |
FRR (False Rejection Rate) | < 0. 1% |
FAR (False Acceptance Rate) | < 0. 0001% |
LFD | O |
