VSCAN-S30MA

USB Stamp / Fingerprint Scanner

VScan-S30 MA is a USB type scanner that can be used as both a seal or stamp scanner and fingerprint scanner. VScan-S30MA is a digital stamp scanner, using our patented registered technology. Only imprinting actual stamp images without any previous ink remains on the imprinted image.

International standard image format and interface, WSQ fingerprint image compression technology. Resistant to scratches, shocks, vibration, and electric shock, and has excellent recognition rate for wet or dry fingerprints. With the USB 2.0 compatible interface, SDK and demo program, you can build a customized fingerprint authentication system for your environment.

* Applicable field: Paperless business in financial community, Financial transactions, and Identification

Features

Patented Stamp Scanner

·Clear image capture regardless of dust or ink mark
·Fingerprint scanner function

Demo Program and SDK

Scan Type

·Stamp Scan
·Single finger Flat Scan

Specification

Detail Specification VSCAN-S30MA

Fingerprint Type Oval Stamp / Seal
Resolution 500dpi
Platen Size (W x L) 31 x 31 mm
Image Size (W x L) 30 x 30 mm
Rolling mode Capturing Speed N/A
Image Quality Standards X
Operating Temperature 0 ~ 50℃
Ingress Protection X
Operating Humidity 10 ~ 90%, non-condensing
Dimension (W x H x D) 72 x 58.3 x 120.4 mm
Weight (kg) 0.7
Certifications WHQL, KC
Interface USB 2.0 (Data & Power)
Operating System Windows, Android
Heater N/A
