Features

Palm Scanner

·Four finger slaps, single rolls, single flat,
on thumb, half palm, writer’s palm

FBI Certification

·FBI IQS Appendix-F Certification

USB Interface Support

·Compatible interface with USB 2. 0

Demo Program and SDK

Specification

Detail Specification NSCAN-P

Main Fingerprint Type Palm, Writer’s Palm, Four-Finger, Single Finger/Roll
Frame Rate Normal Mode Speed: 1.7 fps (Normal Mode speed)
Fast Mode speed: 13 fps (Palm/Writer`s Palm/Four-Finger)
14 fps (Single Finger/Roll)
Resolution 500 dpi
Platen Size (W x L) 156 x 145 mm
Standard Image Size (W x L) 120 x 130(130×130)mm
One Finger Size (W x L) 23 x 40 mm
Dual Finger Size (W x L) 120 x 130 mm
Four Finger Size (W x L) 120 x 130 mm
Palm Size (W x L) 120 x 130 mm
Writer’s Palm Size (W x L) 40 x 130 mm
Rolling Finger Size (W x L) 40 x 40 mm
Rolled Mode Capturing Speed 14 frames/s
Typical Capture Speed Max. 1.7 frames/s
Image Quality Standards FBI IQS Appendix-F, VCCI
Hardware Camera Resolution 16 Mega Pixels
Camera Sensor size (Inches) CMOS,  1/2.3″
CMOS Image Sensor 1/2.3 Inch
LED Light Color Green
Lens Specification 1 Prism, 3 Mirrors, 6 Lens, Filter
Type of Prism Triangular
Light Source Green Led
LED Indicator O
Operating Temperature 0 ℃ ~ 40 ℃
Operating Humidity 10 ~ 90%, non-condensing
Operating Voltage 12V DC
Maximum Power 4.8 Watts (without heater)
Ingress Protection IP 54
Dimension (W x H x D) 315 x 144.5 x 313.2 mm
Weight (kg) 8.2kg (wiithout heater)
Certification EAC, CE, FCC, KC
Self Heating O
Interface USB 2.0 high speed (data)
Requirement Operating System Microsoft Windows, Android
Support SDK Support SDK



Fingerprint Type Single finger Flat / Single Roll, Dual finger flat,
Four finger slap, Palm, Writers palm
Operating Temperature 0℃ ~ 40℃
Resolution 500 dpi Operating Humidity 10~90%, non-condensing
Speed 1.7 fps (Full area)

12 fps (Rolled mode)

Operating Voltage 12 VDC
Platen Size 155. 9 X 144. 8 mm Dimension 315.0 x 312.0 x 147.0
Sensing Area 130 X 130 mm(5. 12” x 5. 12”) Certification VCCI, Tested USB-IF Compliance test
Image Quality Standards  FBI IQS Appendix-F  Dust Water Resistance  IP43
 Image format  raw, WSQ Interface  USB 2. 0 high speed (data)
Weight  8.4Kg (Main Body)

9.2Kg (Main Body + Bracket)

 Operating System  Win XP / Win7 /Win8 /Win10
