Demo Program and SDK

International Standard Image Format and Interface

·ISO/IEC 19794-2:2005, ISO/IEC 19794-4:2005
·ANSI INCITS 378-2004
·WSQ Fingerprint Image Compression
·NFIQ(NITS Fingerprint Image Quality)

Patented Live & Fake Finger Detection

·Optical sensor and algorithm detect fake fingers (paper,film, silicone,rubber and gelatin)

FBI Certification



Detail Specification NScan-FA

Main Fingerprint Type Single Finger/Roll, Live Finger Detection (LFD)
Frame Rate 15 fps(Single Finger/Roll)
Resolution 500 dpi
Platen Size (W x L) 26 x 27 mm
Standard Image Size (W x L) 20 x 25 mm
One Finger Size (W x L) 20 x 25 mm
Rolling Finger Size (W x L) 20 x 25 mm
Rolled Mode Capturing Speed 15 frames/s
Typical Capture Speed Max. 15 frame/s, Capture Type: Optical (Blue LED)
Image Quality Standards FBI PIV + FAP20
Hardware Camera Resolution 2 Mega Pixels
Camera Sensor size (Inches) CMOS,  1/2.7″
CMOS Image Sensor 1/2.7 Inch FHD Single Chip
LED Light Color Blue Fake Fingerprint Detection
Lens Specification 1 Prism, 3 Mirrors, 2 Lens
Type of Prism Trapezoidal
SDRAM 256K Byte (Internal SDRAM)
DDR2 64M Bytes (External DDR)
Serial Flash 4 M Bytes (1,000 Template)
CPU Blackfin + Processor Core (DSP)
CPU Clock Up to 400MHz
Light Source Blue Led
LED Indicator O
Operating Temperature 0℃ ~ +50℃
Operating Humidity 10 ~ 90%, non-condensing
Operating Voltage USB BUS Power (5V)
Maximum Power 1.45 Watts (without heater / available by USB)
Ingress Protection IP 54
Dimension (W x H x D) 47.2 x 81 x 34.4 mm
Weight (g) 180g
Certification EAC, CE, FCC, KC
Self Heating X
Interface USB 2.0 high speed (data)
Feature Live Finger Detection (LFD) O
Requirement Operating System Microsoft Windows, Android
Support SDK Support SDK


Image Size 20.0 x 25.0 mm Capture Speed 22fps (1920 x 1080)
Image Quality Standards FBI PIV Resolution 500 dpi
Certificate KC, CE, FCC Operating Temp. 0 ~ 50℃
Operating Humidity 10~90%, non-condensing Interface RS232(TTL), USB
Operating System Win XP / Win7 /Win8 /Win10 Dimensions (W x D x H) 47.2 x 81.0 x 34.4
Weight (kg) 175g ±10
