AC-2000

IP65 Fingerprint
Card Terminal with Bluetooth Mobile Key

Features

Bluetooth Support

·Bluetooth-enabled mobile key solution
·UNIS-B PLUS : App for administrators
·V-CARD : App for mobile key users

Open Supervised Device Protocol (OSDP)

·communication protocol support that allows peripheral devices to interface with control panels or other security mgmt. systems

Patented Live & Fake Finger Detection

·Optical sensor and algorithm detect fake fingers (paper,film, silicone, rubber and gelatin)

IP65 Dust / Water Resistance

·Outdoor installation

Specification

Detail Specification AC-2000

Authentication Method Biometric
Dust/ Water Resistance IP65
Memory Max Users 10,000
Fingerprints
(Templates)
10,000(1:1)
1,500(1:N)
Logs 51,000
Images X
Communication With Server TCP/IP
Other Bluetooth
Wireless LAN(Wi-Fi) X
Wiegand OUT O
RS232 X
RS485 OSDP
Wiegand IN O
Display LCD X
Backlight X
Embedded Camera X
Card 125khz-EM O
HID Prox Optional
HID iclass O
13.56MHz Smart Card O
Keypad X
Function keys X
Door Phone X
FP Sensor Platen Area 14.6 X 17.6 mm
Resolution 500 dpi
Authentication
Speed
(1:1) < 0.2 sec
1:N(1,000) < 1 sec
Dimension (W) X (H) X (D) mm 58 X 188 X 51.6
FRR /FAR 0.1% / 0.0001%
Operating Temperature -20 ~ 60℃
