AC-1100

Card Terminal with Camera
Bluetooth Mobile Key

Brochure Download

User Manual Download

Smartphone Application
(UNIS-B plus, imkey)

Access control &
mobile key application by Android, iOS

4.0 inch Color Screen LCD & GUI

Intuitive UI , simplifies operation

Features

Bluetooth Support

·Bluetooth-enabled mobile key solution
·UNIS-B : App for administrators
·V-CARD : App for mobile key users

4.0” Touchscreen LCD & GUI

·Large screen and intuitive UI for easy use

Multi-Language Support

Open Supervised Device Protocol (OSDP)

·communication protocol support that allows peripheral devices to interface with control panels or other security mgmt. systems

VoIP Supported

·IP BX Network(SIP)

Face Detection

·Image capture for higher security

Built-in Camera / W FLASH

·Image acquisition during access
·VGA Color

Easy Data Transfer (USB ON-THE-GO)

·Easy data transfer and firmware upgrade by using USB

Specification

Detail Specification AC-1100

CPU 1 GHZ Single core Memory 512MB RAM + 8GB eMMC(NAND)
LCD 4 Inch Color Touch LCD(Resistive) Max Users 200,000
Power Consumption 12V, Max 580mA (7W)
Communication TCP/IP, RS232, RS485 Wiegand In/Out,
Wireless LAN(optional), Bluetooth
Log Capacity 1,000,000 / 15,000 Images
Dimension 80 x 153 x 18.2 mm Certificates KC, CE, FCC, RoHS
RFID Card Option 125kHZ-EM / 13.56MHz Smart Card / Felica/ HID prox
